The 24V 1.63 kWh EAGLE 2 battery system is tailored for low-voltage applications, including golf carts, RVs, industrial equipment, off-grid power systems, and emergency power supplies. Designed to be a drop-in replacement for traditional lead-acid or lithium batteries, each single battery module packs 1.63 kWh of energy, expandable to 16.3 kWh when connected in parallel.
Reliable Safety and Performance: Utilizing lithium iron phosphate (LiFePO4 or LFP) cells known for their safety, the EAGLE 2 is waterproof and equipped with an intelligent Battery Management System (BMS). The BMS continuously monitors and records cell voltage, ensuring optimal performance and safety. Built-in fire-extinguishing modules and heating elements enable charging in freezing temperatures.
Longevity and Durability: Engineered to endure, the EAGLE 2 boasts a lifespan of over 10 years and can withstand more than 4000 - 6000 cycles at 80% Depth of Discharge (DOD) at a rate of 0.5C°.
Monitoring and Connectivity: Monitor remaining capacity with the LED meter for easy tracking of battery status.
Key Features:
- GC2 form factor
- CANbus communications (optional)
- Self-heating function
- IP67 protection rating
- LED State of Charge indicator
- Smart BMS with auto-cell balancing
Battery Specifications:
- System Voltage: 24V
- Max Continuous Power: 2560W
- Nominal Voltage: 25.6V
- Ah Capacity: 64Ah
- Charge Voltage: 29V
- Bulk Voltage: 29V
- Absorption Voltage: 29V
- Float Voltage: 27.5V
- Low Voltage Cutoff: 24V
- High Voltage Cutoff: 28.8V
Designed For:
- Golf carts
- Utility carts
- 48V UTVs & LSVs
- Lead acid replacement
- Intense heat & cold
- Class A, B, & C RVs
- Camper vans
- Food trucks
- Commercial vehicles
- Emergency backup
